Ilka Metal Industrial Fan

Industrial fan ILKA metal VIK series
Material of fan body and impeller: Steel with electrostatic paint coating
Direction of rotation: Counterclockwise from the impeller side
Fan protection degree: IP54
Motor insulation class: F
Motor operation type: Continuous operation
Fan application: Ventilation of medium and large industrial, commercial spaces, restaurants, parking lots and industrial warehouses
Fan model range Impeller diameter (mm) Voltage (V) Current (A) Power (W) Motor speed (rpm) Ventilation volume (m3/hr) Weight (Kg) Sound intensity (dBA) Insulation class
123Page size:
10
select
Page 1 of 3, items 1 to 10 of 28 items.
1 VIK-30V2S 300 220 0.60 130 2100 2150 3.6 64 F
2 VIK-30A4S 300 220 0.60 115 1350 2000 5.5 58 F
3 VIK-30A6S 300 220 0.45 80 920 1400 5.5 50 F
4 VIK-30A4T 300 380 0.50 130 1400 2100 5.5 58 F
5 VIK-35A4S 350 220 0.70 140 1310 2700 6.2 62 F
6 VIK-35A6S 350 220 0.50 100 900 1900 6.2 53 F
7 VIK-35A4T 350 380 0.50 150 1350 2800 6.2 62 F
8 VIK-40A4S-L 400 220 0.90 160 1250 3300 6.9 63 F
9 VIK-40A4S-H 400 220 1.10 210 1350 4200 8.1 65 F
10 VIK-40A6S 400 220 0.45 90 870 2400 7.1 53 F
VIK-40A4T-L 400 380 0.50 180 1300 3400 7.2 63 F
12 VIK-40A4T-H 400 380 0.65 230 1350 4250 8.1 65 F
13 VIK-45A4S-L 450 220 0.73 155 1275 3700 8.2 62 F
14 VIK-45A4S-H 450 220 1.30 270 1340 5100 9.2 68 F
15 VIK-45A6S-L 450 220 0.48 100 900 2700 8.2 54 F
16 VIK-45A6S-H 450 220 0.80 175 880 4300 7.2 59 F
17 VIK-45A4T-L 450 380 0.50 185 1320 4200 8.2 62 F
18 VIK-45A4T-H 450 380 0.70 270 1330 5300 9.2 68 F
19 VIK-50A4S-L 500 220 1.40 270 1320 5500 10 68 F
20 VIK-50G60-4S-H 500 220 3.2 630 1410 8300 14 71 F
VIK-50A6S 500 220 0.70 140 910 3700 9.3 61 F
22 VIK-50A4T-L 500 380 0.67 270 1340 5600 10 68 F
23 VIK-50G60-4T-H 500 380 1.50 610 1415 8400 14 72 F
24 VIK-60G4S 600 220 3.00 550 1420 10200 18.8 71 F
25 VIK-60G6S 600 220 1.30 260 930 6700 17 62 F
26 VIK-60G4T 600 380 1.50 630 1400 10300 18.7 73 F
27 VIK-63G4S 630 220 3.50 650 1400 10200 20 72 F
28 VIK-63G4T 630 380 1.60 650 1420 10500 19.8 75 F
