LPP linear circulator pump

LEO LPP series linear pumps are mainly used in heating and air conditioning systems to circulate hot or cold water. In these pumps, the body and impeller are made of cast iron. LEO LPP series linear pumps are only available in three-phase models and it is recommended to install them with an electrical panel. The advantages of LEO LPP model steel centrifugal pumps include low noise, reasonable price and uniform flow at the pump outlet. These pumps are suitable for transporting clean water free of solids and non-corrosive materials, and the maximum working pressure in LEO linear circulator pumps is up to 16 bar.
Model Output Head Flow Rate Impeller Body
LPP32-4-0.37/2
1.25 6 m 8.5 m³/h Stainless Steel Stainless Steel
 LPP32-8-0.37/2
1.25 10 m 10 m³/h Stainless Steel Stainless Steel
LPP32-16-1.1/2
1.25 20 m 20 m³/h Stainless Steel Stainless Steel
LPP32-21-1.5/2
1.25 26 m 26 m³/h Stainless Steel Stainless Steel
LPP32-26-2.2/2
1.25 31 m 31 m³/h Stainless Steel Stainless Steel
LPP32-31-3/2
1.25 37 m 37 m³/h Stainless steel Stainless steel
LPP40-13-0.75/2
1.5 16.5m 16.5 m³/h Stainless steel Stainless steel
LPP40-17.5-1.1/2
1.5 21m 21 m³/h Stainless steel Stainless steel
LPP40-20.5-1.5/2
1.5 25m 25 m³/h Stainless steel Stainless steel
LPP40-20.5-2.2/2
1.5 29m 29 m³/h Stainless steel Stainless steel
LPP40-24.5-3/2
1.5 36m 36 m³/h Stainless steel Stainless steel
LPP50-12-1.1/2
2 15m 15m³/h Stainless steel Stainless steel
LPP50-16-1.5/2
2 19m 19m³/h Stainless steel Stainless steel
LPP50-21-2.2/2
2 25m 25m³/h Stainless steel Stainless steel
LPP50-24-3/2
2 29m 36m³/h Stainless steel Stainless steel
LPP50-28-4/2
2 38m 42m³/h Stainless steel Stainless steel
LPP50-34-5.5/2 2

Stainless steel Stainless steel
LPP65-14-2.2/2
2.5 17m 50m³/h Stainless steel Stainless steel Stainless
LPP65-17-3/2
2.5 20m 56 m³/h Stainless Cast Iron Stainless Cast Iron
LPP65-21-4/2
2.5 24m 60 m³/h Stainless Cast Iron Stainless Cast Iron
LPP65-28-5.5/2
2.5 33m 70 m³/h Stainless Cast Iron Stainless Cast Iron
LPP65-35-7.5/2 21/2

Stainless Cast Iron Stainless Cast Iron
LPP80-8.5-1.5/2 3

Stainless Cast Iron Stainless Cast Iron
LPP80-14-3/2
3 17m 75 m³/h Stainless Cast Iron Stainless Cast Iron
LPP80-20-5.5/2
1.25 25m 90 m³/h Stainless steel Stainless steel
LPP80-28-11/2 3

Stainless steel Stainless steel
LPP100-16-7.5/4
4 19m 140 m³/h Stainless steel Stainless steel
LPP100-20-11/4 4

Stainless steel Stainless steel
LPP100-30-18.5/4 4

Stainless steel Stainless steel
LPP125-24-15/4 5

Stainless steel Stainless steel
LPP250-50-132/4
4 19m 140 m³/h Stainless steel Stainless steel
